TunaTank XL

15-tube live bait system. Patent pending. Made in USA.

The TunaTank XL puts 15 tubes of live bait on any boat with a 30-amp 12V circuit. 5,500 GPH of total flow on just 18.5 amps. No installation, no built-in livewell required.

Built for serious offshore programs

If your boat has a raw water pump and a 30-amp electric reel outlet, you have a TunaTank-ready vessel. Plug in, run all 15 tubes at 5,500 GPH of flow, and pull only 18.5 amps total — well under the 30 amps that every electric reel circuit on your boat is already rated for.

Engineering in every tube

Each tube is fitted with a soft silicone nose cone that only makes contact with the bait in spots that are durable. Before water reaches each bait, it passes through two stages of water diffusers, so flow stays even and steady across all 15 tubes.

Ask any captain running a TunaTank — what blows them away is how long baits stay strong and lively.

What's included

• TunaTank XL - 15 Tube System (3.65" × 3.15" × 15.5")
• 5 × 1100 GPH recirculation pumps
• 1 × 800 GPH overflow pump
• 85 QT Yeti tank (insulated reservoir)
• Inline switch box with stainless steel push button switch
• Custom power cord — your selected plug and length
• Soft silicone nose cones (factory installed)

Specifications

Tube count — 15

Tube dimensions — 3.65" × 3.15" × 15.5"

Overall dimensions — 26" × 26" × 24"

Recirculation pumps — 5 × 1100 GPH high-flow

Overflow pump — 1 × 800 GPH high-flow

Total flow — 5,500 GPH

Power draw — 18.5 amps at 12V

Voltage — 12V (24V available on request)

Reservoir — 85 QT Yeti tank (included)

Connection options — Hubbell 30A, Krystal 32A, Marinco 2- or 3-Prong

Power cord length — 5, 10, 15, or 20 ft (custom on request)

Built to order in the USA

Every TunaTank XL is built to order. Standard lead time is 2–4 weeks. Each system ships with a 6-month limited warranty; extended 2-year coverage is available at checkout or on request.

Pickup only

The XL is currently available for local pickup only due to its size. Reach out before ordering if you need to coordinate a freight option.

Trusted by captains

Tournament results and captain testimonials from boats running the XL — coming soon.
